16-Port ACS8000 Console System with dual Vertiv Avocent ACS8000 Serial Console - 16 port Console Server | Modem | Dual AC - Advanced Serial Console Server | Remote Console | In-band and Out-of-band Connectivity | 16 port rs232 terminal | Dual AC power | Analog Modem | 2-Year Full Coverage Factory Warranty - Optional Extended Warranty Available
Vertiv Artikelnummer ITR-7E68B00266
16-Port ACS8000 Console System with dual
16-Port ACS8000 Console System with dual Vertiv Avocent ACS8000 Serial Console - 16 port Console Server | Modem | Dual A...
€ 4.677,56
incl. BTW
Beperkte voorraad
LeveringWordt bij het afrekenen voor uw adres berekend
GarantieFabrieksgarantie van toepassing
RetournerenBekijk retourbeleid
Specificaties
- Certification
- FCC Class A, CE Class A (EU), ICES-003 (Canada), VCCI (Japan), RCM (Australia), Customs Union (CU), KCC (Korea), UL (USA), cUL (Canada), EN-60950 (EU), CB, Customs Union (CU)
- Rack mounting
- Yes
- Internal modem
- Yes
- Zero Touch Provisioning (ZTP)
- Yes
- Web-based management
- Yes
- Temperature sensor
- Yes
- Product colour
- Black
- Management protocols
- CLI, HTTP/ HTTPS, SNMP
- Flash memory
- 16000 MB
- RAM capacity
- 1024 MB
- RAM type
- DDR3L
- eMMC capacity
- 16 GB
- Copper ethernet cabling technology
- 10BASE-T, 100BASE-T, 1000BASE-T
- Cable types supported
- Cat5, Cat5e, Cat6, Cat6+, Cat6a, Cat6e, Cat7, Fiber
- Operating temperature (T-T)
- -10 - 60 °C
- Storage temperature (T-T)
- -20 - 70 °C
- Operating relative humidity (H-H)
- 20 - 80%
- Storage relative humidity (H-H)
- 5 - 95%
- Console port
- RJ-45
- Serial ports quantity
- 16
- USB 2.0 ports quantity
- 8
- Ethernet LAN (RJ-45) ports
- 2
- SFP module slots quantity
- 2
- AC outlet types
- C13 coupler
- Power source type
- AC
- AC input voltage
- 103 - 240 V
- AC input frequency
- 50 - 60 Hz
- Power consumption (typical)
- 20 W
- Power consumption (max)
- 35 W
- Input current
- 0.1 A
- Number of power supply units
- 2
- Processor family
- ARM Cortex-A9
- Processor architecture
- ARM Cortex-A9
- Processor cores
- 2
- Processor frequency
- 667 MHz
- Security algorithms
- 3DES, 128-bit AES, 192-bit AES, 256-bit AES, AES, FIPS 140-2, HTTPS, IPSec, SHA-256, SNMP, SNMPv3, SSH, SSH-2
- Authentication method
- LOCAL,LDAP,RADIUS,TACACS+ and OneTimePasswords(OTP)
- IP address filtering
- Yes
- One-time password (OTP)
- Yes
- Operating system installed
- Embedded LINUX
- Safety
- UL (USA), cUL (Canada), EN-60950 (EU), CB, Customs Union (CU)
- Dimensions (WxDxH)
- 438.2 x 241.3 x 44.5 mm
- Weight
- 3.4 kg
