4 Port Gigabit PoE PCIe Network Card StarTech.com 4 Port Gigabit Power over Ethernet PCIe Network Card - PSE / PoE PCI Express NIC - Quad Port NIC - PoE Card - PCI Express x4 - 4 Port(s) - 4 - Twisted Pair
Startech.Com SKU ITR-5FF3FF8629
4 Port Gigabit PoE PCIe Network Card
4 Port Gigabit PoE PCIe Network Card StarTech.com 4 Port Gigabit Power over Ethernet PCIe Network Card - PSE / PoE PCI E...
€389.49
incl. VAT
In stock
DeliveryCalculated for your address at checkout
WarrantyManufacturer warranty applies
ReturnsView return policy
Specifications
- Internal
- Yes
- Chipset
- RTL8111E
- LED indicators
- Link, PoE
- Certification
- CE, FCC, REACH, TAA
- Harmonized System (HS) code
- 85176990
- Master (outer) case width
- 402 mm
- Master (outer) case length
- 510 mm
- Master (outer) case height
- 324 mm
- Products per master (outer) case
- 14 pc(s)
- Maximum data transfer rate
- 2000 Mbit/s
- Networking standards
- IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
- Ethernet LAN
- Yes
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Cabling technology
- 10/100/1000BaseT(X)
- Wake-on-LAN ready
- Yes
- Auto MDIX IEEE
- Yes
- Full duplex
- Yes
- Jumbo frames support
- Yes
- Jumbo frames
- 9000
- Operating temperature (T-T)
- 0 - 55 °C
- Storage temperature (T-T)
- -40 - 75 °C
- Operating relative humidity (H-H)
- 10 - 90%
- Buffer size
- 48 KB
- Peripheral (Molex) power connectors (4-pin)
- 1
- Number of SATA power connectors
- 1
- Manual
- Yes
- Drivers included
- Yes
- Package width
- 191 mm
- Package depth
- 296 mm
- Package height
- 71 mm
- Package weight
- 428 g
- Connectivity technology
- Wired
- Host interface
- PCI Express
- Interface
- Ethernet
- Ethernet LAN (RJ-45) ports
- 4
- PCI Card form factor
- Full-height
- Output voltage
- 48 V
- Windows operating systems supported
- Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 2000, Windows 2000 Professional, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
- Linux operating systems supported
- Yes
- Server operating systems supported
- Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
- Compliance certificates
- RoHS
- Width
- 18 mm
- Depth
- 243 mm
- Height
- 120 mm
- Weight
- 102 g
