Startech.Com SKU ITR-1A0136109B

PCIe Serial Port Card - 16C1050 UART

PCIe Serial Port Card - 16C1050 UART StarTech.com 1-Port PCI Express Serial Card, PCIe to RS232 (DB9) Serial Interface C...

٥٨٫٤٦ € شامل الضريبة
متوفر
اطلب عرض سعر →
التسليميُحسب لعنوانك عند الدفع
الضمانينطبق ضمان الشركة المصنعة
PCIe Serial Port Card - 16C1050 UART StarTech.com 1-Port PCI Express Serial Card, PCIe to RS232 (DB9) Serial Interface Card, 16C1050 UART, COM Retention, Low Profile, Win & Linux - Connect a serial RS232 (DB9) device using this PC Serial Card. Supports 16C1050 UART. LED lights to monitor activity on the PCI express DB9 card - The UART PCIe card supplies 5/12V over pin 9. Continue using legacy hardware with this RS232 PCIe card

المواصفات

Internal
Yes
Product colour
Yellow
LED indicators
Activity
Chipset
ASIX - AX99100, ASIX - ZT3243LFEY
Baud rate
921.6 Kbit/s
FIFO (First In, First Out)
256 B
Data bits
5, 6, 7, 8, 9
Flow control support
Yes
Parity bit
Even, Mark, No, Odd, Space
Harmonized System (HS) code
84733020
Products per master (outer) case
50 pc(s)
Master (outer) case width
530 mm
Master (outer) case length
440 mm
Master (outer) case height
340 mm
Operating temperature (T-T)
0 - 55 °C
Storage temperature (T-T)
-40 - 75 °C
Operating relative humidity (H-H)
5 - 95%
Material
Steel
Mounting brackets included
Yes
Quick installation guide
Yes
Package width
145 mm
Package depth
212 mm
Package height
41 mm
Package weight
200 g
Host interface
PCIe
Output interface
Serial
Expansion card form factor
Full-height / Low-profile
Expansion card standard
PCIe 2.0
Serial ports quantity
1
Serial interface type
RS-232
Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Linux operating systems supported
Yes
Server operating systems supported
Windows Server 2016, Windows Server 2019
Compliance certificates
CE, RoHS
Width
65 mm
Depth
67 mm
Height
18 mm
Weight
42 g
