Startech.Com SKU ITR-72869A11DE

PCI-E RS232 Serial Card Asix AX99100

PCI-E RS232 Serial Card Asix AX99100 StarTech.com 2-port PCI Express RS232 Serial Adapter Card - PCIe to Dual Serial DB9...

٥٧٫٠٠ € شامل الضريبة
غير متوفر
اطلب عرض سعر →
التسليميُحسب لعنوانك عند الدفع
الضمانينطبق ضمان الشركة المصنعة
PCI-E RS232 Serial Card Asix AX99100 StarTech.com 2-port PCI Express RS232 Serial Adapter Card - PCIe to Dual Serial DB9 RS-232 Controller - 16950 UART - Windows, macOS, Linux - 2-port PCI Express RS232 serial controller card 16950 UART/ASIX AX99100 - Bi-directional speeds 921.6Kbps/port | 256 byte FIFO | 9th data bit - Pin 9 pwr out 5v/12v/none w/up to 2A total - Expansion card w/ Std bracket (low profile incl) - Win/Linux

المواصفات

Internal
Yes
Product colour
Green
Mean time between failures (MTBF)
222366 h
Chipset
Asix AX99100
Baud rate
921.6 Kbit/s
FIFO (First In, First Out)
256 B
Data bits
5, 6, 7, 8, 9
Stop bits
1, 1.5, 2
Parity bit
Even, Mark, No, Odd, Space
Flow Control type
No, RTS/CTS, XON/XOFF
Harmonized System (HS) code
84733020
Products per master (outer) case
75 pc(s)
Master (outer) case width
359 mm
Master (outer) case length
690 mm
Master (outer) case height
310 mm
Operating temperature (T-T)
-10 - 80 °C
Storage temperature (T-T)
-20 - 100 °C
Operating relative humidity (H-H)
5 - 85%
Quantity
1
Quick installation guide
Yes
Package width
144 mm
Package depth
170 mm
Package height
30 mm
Package weight
136 g
Host interface
PCIe
Output interface
Serial
Expansion card standard
PCIe 1.1
Serial ports quantity
2
Serial interface type
RS-232
Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Linux operating systems supported
Yes
Server operating systems supported
Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Sustainability compliance
Yes
Compliance certificates
CE, RoHS
Width
63 mm
Depth
75 mm
Height
15 mm
Weight
56 g
